SATEL
The BE WAVE wireless devices you are planning to install must be within the range of the controller's radio
communication. Keep this in mind when selecting a place of installation for the controller. Please note that thick
walls, metal partitions, etc. will reduce the range of the radio signal.
If the controller is to meet the requirements of Standard EN 50131 for Grade 2, mount the controller on
the wall.
Do not mount the controller on the wall with cables pointing upwards.
If the controller is to remain placed on the tabletop, skip steps 2, 3 and 5 and apply adhesive anti-slip
pads on the bottom of the enclosure (Fig. 13). The pads are supplied with the controller.
1. Open the controller enclosure (Fig. 1).
2. Place the enclosure base against the wall and mark the location of mounting holes (Fig. 3). If the controller
is to detect removal from the surface, mark the location of the hole in the tamper protection element –
indicated with the
3. Drill the holes in the wall for wall plugs (anchors). Select wall plugs specifically intended for the mounting
surface (different for concrete or brick wall, different for plaster wall, etc.).
4. Run the cable(s) through the hole in the enclosure base (Fig. 4).
5. Fasten the enclosure base to the wall with screws (Fig. 5).
6. Insert a mini SIM card into the SIM1 slot (Fig. 6) [Smart HUB Plus].
7. If you want to use two SIM cards, insert the second mini SIM card into the SIM2 slot (Fig. 7)
[Smart HUB Plus].
8. If the controller is to be connected to the wired LAN network, connect the cable to the LAN port (Fig. 8). Use
a cable compliant with the 100Base-TX standard with the RJ-45 plug (the same as for connecting the
computer to the network).
The controller can only operate in the local area networks (LAN). It must not be connected
directly to the public computer network (MAN, WAN). To establish connection with a public
network, use a router or xDSL modem.
9. Connect the power cable to the power cable port in the controller (Fig. 9) and secure the cable fastener with
screws (Fig. 10).
10. Remove the battery insulator tag (Fig. 11). The controller will power on (the controller LED indicator will start
flashing).
11. Close the enclosure and secure it with screws (Fig. 12).
12. Plug the power cable to the power outlet.
13. Start the Be Wave app to configure the controller settings and add BE WAVE devices. You can download
the app from "Google Play" (Android system devices) or "App Store" (iOS system devices).
Replacing the rechargeable battery
Be particularly careful when replacing the battery. The manufacturer is not liable for the
consequences of incorrect installation of the battery.
The used batteries must not be discarded, but should be disposed of in accordance with the
existing rules for environment protection.
The battery will not be charged in temperatures below 0°C.
When the Be Wave app indicates that the rechargeable battery needs to be replaced:
1. Start the diagnostics mode in the Be Wave app.
2. Open the controller enclosure.
3. Remove the old battery (Fig. 14).
4. Install the new battery (Fig. 15).
5. Close the enclosure and secure it with screws.
6. Close the diagnostics mode in the Be Wave app.
Hereby, SATEL sp. z o.o. declares that the radio equipment type Smart HUB Plus / Smart HUB is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the
Smart HUB Plus ● Smart HUB
symbol in Fig. 3 (requirement of Standard EN 50131 for Grade 2).
following internet address: www.satel.pl/ce
