5. DescripTion
5.1. Area of application
The 8200 hygienic holder is intended for professional use in process
measurements technology, as a holder for probe with a 12 mm
shaft diameter. Depending on the version, the hygienic holder can
either be installed on a weld-in socket with a diameter of 25 mm or
a clamp connection or a 2" (DN50/40) connection adapted for GEA
Tuchenhagen VARINLINE process connections.
5.2. Available versions
The hygienic holder is available in the following versions:
process connection
G1¼" internal thread
*
G1¼" internal thread
*
2" (DN50/40) connection
adapted for GEA Tuchenhagen
VARINLINE process connections
Clamp 1½", (dia. 50.5 mm)
The certificate 3.1 is supplied with the holder.
*
Type 8200
Description
specification order code
O-ring position
562431
(OP): 25 mm
O-ring position
562432
(OP): 50 mm
Inclination: 15° 562433
*
Insertion lenght:
558885
33 mm
6. TechnicAl DATA
6.1. conditions of use
Fluid temperature 135°C max.
Temperature limits may depend on the
inserted probe. Refer to the relevant
operating instructions. If the temperature
ranges given for the holder and the
inserted probe are different, use the most
restrictive range.
Pressure class 6 bar max.
Pressure limits may depend on the
inserted probe. Refer to the relevant ope-
rating instructions. If the pressure ranges
given for the holder and the inserted
probe are different, use the most res-
trictive range.
6.2. materials
part material
Body Stainless steel
O-ring EPDM (FDA agreement)
