When the choke stands on the closed position, the fuel mixture gets concentrated for
starting of the cold engine. The position OPEN produces the right fuel mixture for the
usual operation after starting and for starting the machine when the engine is hot.
 Adjust the throttle control 11 (Fig. D) at half throttle.
 Grab the starting handle (Fig. E) and start moving it slowly. At one position the resistance
gets very hard. Let the cable rewind a bit and pull on it powerfully.
ATTENTION:
NEVER pull the cable till the end of it.
NEVER skip the cable after pushing on it. Let it rewind.
 Start the engine with the starting handle.
 Let the plate compactor running warm for about 2 minutes at half throttle.
 Set the wished engine speed with the throttle control and start working.

11.4.2 Stopping

 Turn back the throttle control to idling mixture
 Turn off the ignition
 Close the petrol cock.
 Before storing the machine it must get cold.

11.4.3 Operating instructions

 Operate the machine by postponing the handle sidewise.
 Always hold a good stand do that you can't slide or lose the control of the machine.
 When the machine has an optional water tank you can adjust the flowing speed by using
the cock in the tube.
 One meter around the machine and into the working direction there mustn't be any person
except of the operator.
 During tamping and raising of an earth building you have to tamp about 100 to 150 mm
inside the edge two or three times. Then you can tamp the edge.
 When tamping earth in the middle of a building the plate shouldn't touch the reinforced
concrete piles, the underground construction the ground of the machine and the
underground pipes.
 During workings in the inside of a building the plate and the eccentric block mustn't strike
the walls.
 When lots of machines work together, the distance between the front machine and the
machine that is behind it should be at least 10 m. The parallel distance shouldn't be less
than 5 m.
 When the machine works on soft or rough ground you have to decrease the engine speed
by using the throttle control so that the machine doesn't sink. When there is a descent you
have to take care that the plate compactor doesn't faint.
 You have to take care extremely in the following dangerous areas:
At tunnel workings you have to cater for a good ventilation to avoid accidents. There

must be a functioning control system for the supply of fresh air.
Near landlines there's a high danger of electrical shocks. Only the operator should be

in the working area when the working area is very dangerous.
During working and parking you have to take care of the stability of the machine to

avoid dangers.
