Assembly and operating instructions Type ALE3B5FS00
65 A bidirectional three-phase active power energy meter with S-Bus interface, Pic. 1
Description
Energy meter with S-Bus interface enables the reading of
all relevant data like meter reading, electricity, voltage and
power (active and reactive).
Technical data
■ Pic. 2
Connection
diagram
■ Pic. 3
Dimensions
■ B according to EN50470-3,
Accuracy class
1 according to IEC62053-21
■ I
Reference, Maxi-
ref
mum, initial current
■ 3 × 230/400 V
operating voltage
Tolerance −20%/+15%
■ 00 000,00...999 999,9 kWh
Counting range
■ 1000 Imp/kWh
LED-Ouptut
■ Conductor cross-section 1,5−16 mm
Connections
Main circuit
screwdriver pozi no. 1, slot no. 2,
torque 1,5−2 Nm
■ Conductor cross-section max. 2,5 mm
Connections
Control circuit
screwdriver pozi no. 0, slot no. 2,
torque 0,8 Nm
■ −25... +55°C (noncondensing
Operating
temperature
according standard EN50470)
■ Mechanical M2
Environment
Electromagnetic E2
Indicating elements (Pic. 4)
■ Shows total consumption Tariff
T
(kWh)
total
■ Shows partial consumption , this
T
(kWh)
part.
value is resettable
■ Shows total feeding back Tariff
T
(kWh)
total
■ Shows partial feeding back,
T
(kWh)
part.
this value is resettable
■ Shows the instantaneous power
P(kW)
per phase or all phases.
Current
Current
■ Shows the voltage per phase
U(V)
■ Shows the current per phase
I(A)
■ Shows the unit kWh when the
kWh
consumption is displayed
■ For P-, U-, I- or Error display, the
L1 / L2 / L3
corresponding phase is displayed
■ In case of missing phase, the
Error
corresponding phase is addition-
ally displayed.
4 319 5128 0b
= 10 A, Im
= 65 A, Ist
40 mA
ax
=
, 50 Hz
AC
= consumption (pos.)
= feeding back (neg.)
Notes before connecting
1. Do not connect L1, L2 or L3 to N
2. In order to avoid moisture in the meter due to condensa-
te build-up, acclimatise the meter at room temperature
for about half an hour before connecting.
3. N must always be connected.
Attention!
These devices must only be installed by a professional
electrician, otherwise there is the risk of fire or the risk of
an electric shock.
Installation instructions
The three-phase energy meter can be attached to a 35 mm
rail (EN60715TH35).
The meter can be used only in installation cabinets.
,
2
Method of operation (Pic. 5)
Energy is added as indicated by the arithmetic operator.
,
2
Positive output in the meter indicates that energy is being
supplied, while negative output indicates that energy is
being delivered.
Declaration of Conformity CE
We, Saia-Burgess Controls AG, CH 3280 Murten (Switzer-
land), herewith declare, on our own responsibility that
the products:
■ ALE3B5FS00C3A00
which this certificate refer to, are in accordance with the
directive 2004/22/EG (MID) and the following standards:
■ EN50470 parts 1 and 3 (electronic meter), of
October 2006.
Murten, 30.04.2013
Conformity Assessment Body:
METAS-Cert, Nr. 1259
CH-3003 Bern-Wabern
Signed: Jean-Paul Costa, Head of development
09.2013
English
Subject to change without notice
