E N
6. Operations and use.
Do not use glue, sealant or other chemical products on threads or other product parts.
To disconnect the product from the power mains, remove the power plug from the power outlet without pulling on the power cord.
6.1. Operating description.
The filter media is the cartridge, which consists of a particular cloth that is able to stop solid residue that can be present in the pool. The
functioning of the filter is assured by a permanent magnet synchronous pump motor that enables combining high performance with low
consumption and limited maintenance. The pump takes in water from the pool through a suction pipe (IN – Fig. 12), makes it pass through the
filtering cartridge and then returns it to the pool by means of a delivery pipe (OUT – Fig. 12).
6.2. Application range.
The product cannot be used to purify water for human consumption.
The product cannot be used to purify liquids other than fresh water.
The product was designed and constructed to operate in above-ground fresh pool, located outdoors.
6.3. Use.
Cutting, replacing and/or altering the power cord is strictly prohibited.
The product cannot be used to purify water for human consumption.
The product cannot be used to purify liquids other than fresh water.
The product cannot be used for medical/therapeutic purposes,
6.4. Operating limits and environmental limits.
•
Maximum water temperature: 35 [°C].
•
Minimum water temperature: 4 [°C].
6.5. Safety devices and signalling.
The product is equipped with a thermal protector. Following any thermal protector operation, check the causes that originated the product's
malfunction. For this purpose, please consult the "Troubleshooting" section.
The product shall go back to normal operating conditions after it has cooled down (about 2÷3 hours) and/or the caused that triggered the
thermal protector have been eliminated.
6.6. Hazards and risks.
Attention to the inlet/outlet points because they can trap parts of the body and/or hair and cause serious personal injuries and even death
(Fig. 5).
Pumps, filters, and other equipment/components of a pool filtration system can operate under pressure. If not correctly installed they can
cause serious personal injuries and even death (Fig. 4, Fig. 6).
The product is powered electrically and works in the water, so maximum diligence in its installation and maintenance is required, in order to
avoid danger. Please pay particular attention to:
•
the conditions of its power cord, which must not be damaged;
•
the conditions of the rotor, which must always be in optimal conditions.
7. User instructions.
7.1. Foreseen use and adjustments.
We suggest to start the filter twice a day for 4 or 5 hours.
8. Routine, scheduled and extraordinary maintenance.
Before proceeding with any maintenance activity, remember to disconnect the power plug from the power outlet, and not to put your hands
in the water if the product (pump) is turned on.
When the performance worsens and at least once a year, it is necessary to check the product and check the wear of the rotor and bearing
and, if necessary, replace worn out parts.
Do not lubricate and/or use detergents and/or chemical products to clean the product.
Replace any damaged and/or worn components as quickly as possible; use only original spare parts. For this purpose, please consult the
"Retail and spare parts and relevant documentation".
8.1. Routine maintenance.
To be performed at least once a year, or more frequently if necessary.
Product components that, due to their normal use, suffer wear and/or tear must be regularly replaced to ensure good product performance.
The following table shows the perishables and/or consumables used in the product and their estimated working life.
8.1.1. Filter cleaning.
In order to avoid dirt that has accumulated in the cartridge from decreasing the flowrate, the cartridge must be cleaned regularly or replaced.
Follow these steps for this purpose:
1. Unplug the product power plug.
2. Place the filter above the water level.
3. Unscrew the ring nut and remove the cartridge from the filter body.
4. Rinse the cartridge under running water or replace it with a new one (Fig. 14).
5. Put the cartridge back into the filter.
6. Close the ring nut and connect the filter to the pool.
7. Start up the filter by following the instructions at paragraph 5.6.2.
8.2. Extraordinary maintenance.
This consists in replacing worn or damaged parts (cartridge, bearing, rotor, impeller, etc.).
Nome file:
7521002 - ISTRUZIONI FILTRO A CARTUCCIA.docx
File name:
O rings and general seals
Rotor
Bearing
15-32
1 year
1 year
1 year
Rev. 1 26/09/2014
