E N
The product with transformer (12 [V]) can be placed near the edge of the pool while the transformer is always kept at a minimum distance
of 3.5 [m] from the edge of the pool.
Considering the following aspects is recommended:
•
Dimensions and position of hydraulic components.
•
Necessary clearance.
•
Power cord position.
•
Location of the power supply (electrical socket, at least 3,5 [m] from the edge of the pool).
•
Support and its location.
Make sure the product is positioned in a place where noise generated during normal operations does not create disturbances.
The product must be positioned in a shady and aerated place.
5.6. Connections and start-up.
The product must be installed and operated by individuals with appropriate training.
The electrical system must meet current international and/or national regulations.
The product must be connected to an power outlet equipped with a residual current device with sensitivity over 30 [mA]. Before starting the
product make sure this device is installed in your electrical system. Contact a technician if necessary.
Make sure the product complies with your electrical system.
The power outlet must be at a suitable distance from the water but easily accessible in order to be able to easily turn off the product in the
event of fault (electrical socket, at least 3,5 [m] from the edge of the pool). Cutting the power cord and/or replacing the power plug is strictly
prohibited.
The power cord must be positioned to avoid possible damages such as bends and/or cuts (Fig. 11).
The cover (Fig. 7, # 5, 6) must be tightly screwed-in before connecting the product to the power mains.
5.6.1. Hose connection.
Proceed as follows:
1. Connect the inlet pipe (hydraulic part) to the IN rubber holder (Fig. 12) and the outlet pipe to the OUT rubber holder (Fig. 12). Fix the pipes
(hydraulic part) with clips.
2. Check the hydraulic pipe is as short as possible to minimize the decrease in flowrate. Avoid any deformation or occlusion in the hydraulic
pipes because they might affect the product operation.
3. Support the inlet and outlet pipes (hydraulic parts) of the product in order to minimize the load on it.
5.6.2. Priming.
To make priming the product easier please follow the procedure shown in Fig. 15.
Slowly fill the product with clean water from the outlet pipe, checking the inlet pipe fills with water too (Fig. 15, OUT). Switch the product on
only when all the hydraulic parts are filled with water, inserting the plug into the socket and start the pump and drain air (Fig. 13).
5.7. Reinstallation and reuse.
Clean the product and the moving parts accurately before stopping the product for a while, such as, for instance, during the winter months.
Do not lubricate and/or use detergents and chemical cleaning products.
If there is the risk of freezing, the product must be carefully emptied from the liquids in its hydraulic circuit. It is advisable to empty all the
hydraulic parts.
5.8. Demolition and disposal.
Collecting recyclable material, both those used for packaging (cardboard, nylon, etc.) and those replaced during maintenance is
recommended. Suitable collection of waste material for recycling, processing and environmentally compatible disposal contributes in avoiding
possible negative effects on the environment and health and promotes the reuse and/or recycling of product materials.
Illicit product disposal by the user may be punishable by current international and/or national laws.
5.8.1. Electric/electronic waste disposal.
EU directive 2002/96/EC classifies this product as an electrical or electronic tool. The barred bin symbol on the equipment or packaging
indicates that the product must be separated from other waste at the end of its working life. Therefore, the user must take equipment to
electronic and electro-technical waste collection centres at the end of its working life or return it to the dealer when purchasing similar new
equipment, on a one to one basis. Suitable collection of decommissioned equipment for recycling, processing and environmentally compatible
disposal contributes in avoiding possible negative effects on the environment and health and promote the reuse and/or recycling of device
materials. Illicit product disposal by the user may be punishable by current national laws.
