2.3. General and safety warnings.
2.3.1. General warnings.
SHOTT International srl continuously strives to improve its products. We trust the user will understand the technical modifications SHOTT
International srl reserves the right.
SHOTT International srl is not liable for any damages due to improper product use.
Carefully read and keep the user manual.
In order to increase energy savings, only use the product when necessary.
The following paragraphs include all the instructions necessary to best use the product according to your needs and to independently
perform the cleaning and maintenance operations that this type of product requires. The references (#) in parentheses correspond to the parts
indicated in the diagram (see Fig. 7).
Upon product receipt and/or purchase, check packaging integrity. The product must be accompanied by the user manual. The user manual
must be complete.
In the event of malfunctions, consult the user manual and, if necessary, contact specialised technicians.
Failure to observe the instructions in this user manual immediately null and voids the warranty.
Respect current regulations regarding accident prevention.
Due to the complex nature of the cases treated, the installation, user and maintenance instructions contained in this customer manual do
not seek to examine all possible and imaginable cases of service and maintenance. Should your require additional instruction or have specific
problems, please do not hesitate to contact the distributor or the product manufacturer directly.
2.3.2. Safety warnings.
The product is not suited for people (even children) who suffer from physical, sensorial or mental handicaps or people who do not have
sufficient experience or training unless instructed on product use and assisted by a person in charge of their safety. Supervise children to
ensure they do not play with the product.
The product (pump) must never be operated in the swimming pool when people are present.
Do not submerge the product in water (Fig. 3).
Be sure to disconnect the power plug from the power outlet before operating on the product.
Attention to the moving parts (Fig. 4).
Attention to the inlet/outlet points because they can trap parts of the body and/or hair and cause serious personal injuries and even death
(Fig. 5).
Pumps, filters, and other equipment/components of a pool filtration system can operate under pressure. If not correctly installed they can
cause serious personal injuries and even death (Fig. 6).
Packaging materials are not children's toys. Films can be hazardous and cause suffocation.
Do not drink alcoholic beverages before, after and while swimming. Alcohol consumption may cause drowsiness, loss of consciousness
and consequent drowning.
If taking drugs that induce drowsiness (i.e.: tranquillizers, antihistamines or anticoagulants), avoid swimming in heated pools.
Do not use the pool if the product (filter/pump) cannot be used.
In order to protect the users' health do not use the pool immediately after treating the water, wait for a length of time compliant with the
current health regulations.
3. Product presentation.
3.1. Product scope.
The cartridge filters of the CF series are mechanical filters that have been designed to filter water in private aboveground pools.
3.2. Composition.
See Fig. 7.
4. Technical specifications and features.
See Tab. 1 in Fig. 1.
The hydraulic parts used for the building of the system which shall include the product modify the performance (head and flowrate) of the
product.
5. Installation.
5.1. Necessary tools.
See Fig. 8.
5.2. Storage features and conditions.
Store the product in a dry place and keep away from the elements.
5.3. Transport.
Handle the product with care to avoid damages.
5.4. Handling.
Handle the product with care to avoid damages.
5.5. Positioning.
The product must be positioned under head (Fig. 9).
The product must be placed in an area not subject to flooding.
The product cannot be used on the water surface.
The product must always be located at least 3.5 [m] from the edge of the pool from which water is drawn (Fig. 10).
Nome file:
7521002 - ISTRUZIONI FILTRO A CARTUCCIA.docx
File name:
# #
1 Cartridge 7
2 Filter body 8
3 Draining tap (air) 9
4 Filter body gasket 10 Transformer (only for 12V versions)
5 Filter body cover 11
6 Lock nut 12
Pump
Outlet union
Filter base
Lock nut
Gasket
Tab. 6
