DOEPFER MUSIKELEKTRONIK A-100 Betriebs- Und Einbauhinweise Seite 11

(2) fuse holder
and fuse
mounting hole
5V voltage regulator
soldering points for
optional flat connectors
(3) control LEDs for
+5V, +12V and –12V
(4) pin headers for
module connection
(1) IEC socket for
mains connection
power supply
module
separating line (if supply
unit and bus board are
used separately)
mounting holes
