ASSEMBLY
1
Hardware Qty
Z10 Bolt (M10x110L-15L) 14
Z17 Bolt (M10x25L) 3
Z18 Arc Washer (M10) 23
Z19 Bolt (M10x80L-35L) 2
Z20 Washer (M10) 8
F11 Nut (M10) 16
F50 Flat Washer (M10) 4
Torque Value
45 Nm / 33 ft-lb
35 Nm / 26 ft-lb
Use shims if base is not level.
2
Hardware Qty
L11 Spring Washer (M8) 2
L14 Screw (M5x16L) 4
L17 Bolt (M8x20L) 2
L42 Screw (M6x15L) 2
F48 Flat Washer (M5) 4
K12 Snap Ring 4
Z13 Flat Washer (M8) 2
Z10x8
Z20x8
F11x8
Z18x8
Z10x6
Z18x12
Z17
F11x6
Z18
Z17x2
Z18x2
F11x2
F50x4
L14x4
F48x4
K12x4
L42x2
Z13x2
L17x2
L11x2
ENGLISH
3
Hardware
Z07 Bolt (M12x25L)
Z08 Flat Washer (M12)
Z09 Spring Washer (M12)
Z19x2
4
Hardware
B26 Bolt (M10x25L)
Z13 Flat Washer (M8)
Z14 Bolt (M8x20L)
5
Qty
2
2
2
Qty
3
2
2
B26x3
Z09x2
Z08x2 Z07x2
Z14x2
Z13x2
