como 14
A NO RD N U N G
A R R A N G E M E N T
Für die Installation in der Dusche empfehlen wir ein Achsmaß
(Abstand: Mitte Armatur - Mitte Armatur) von 150 mm bis 200
mm.
Für die Installation in der Dusche empfehlen eine Einbauhöhe
von 1000 mm bis 1200 mm von der Fliesen-Oberkante bis
zur Mitte der Armatur.
Beachten Sie zur Anordnung und zum Anschluss der Armaturen
die Montageanleitungen von UP-Einheit DB 1 und DB 3.
Alle Maße in Millimetern.
All dimensions in millimeters.
V.2024.1.1
150-200
COMO 13 /
COMO 14 /
UP-EINHEIT DB 1
UP-EINHEIT DB 3
For installation in the shower, we recommend an axial dimension
(distance: centre of tap - centre of tap) of 150 mm to 200 mm.
For installation in the shower, we recommend an installation
height of 1000 mm to 1200 mm from the upper edge of the tile to
the centre of the tap.
For the arrangement and connection of the tap, please refer to the
installation instructions for concealed units DB 1 and DB 3.
H AN DBRAU SE
H AN DSH OW ER
