20. Screw the hose adapter
connections on the valve head
clockwise.
The filter vessel is prepared.
Fitting the line connections
Some hoses, such as the pressure hose, are very stiff. Place them in the sun before use
so that the heat makes them more flexible.
Only hand-tighten all screw connections. Excessive tightening of the screw connections
damages gaskets and plastic components.
Use suitable pool hoses Ø 32 / 38 mm for the described connections. Other pool hoses (such as INTEX
with threaded connection) require additional adapters.
To connect a swimming pool hose to the pump
or filter vessel, proceed as follows:
1. Guide a hose clamp over the hose.
2. Push the hose onto the hose connection.
3. Fix the hose clamp on the hose connection
using a Phillips screwdriver PH1.
The swimming pool hose is connected.
To connect a swimming pool hose to the hose
adapter of the pump or filter vessel, proceed as
follows:
1. Screw the hose adapter into the connection
thread.
2. Guide a hose clamp over the hose.
3. Push the hose onto the hose adapter.
4. Fix the hose clamp on the hose adapter using
a PH 1 Phillips screwdriver.
The swimming pool hose is connected to the hose
adapter.
into the
12
by turning it
13
14
37
