MP 24 / MP 24 DUO
Fault-Finding
Fault:
Nothing appears on the display when you connect
the charger to a 12 V car battery.
Cause:
You have connected the battery clips the wrong way
round (reverse polarity).
Remedy: Check and correct polarity.
RED = POSITIVE (+)
Fault:
Nothing appears on the display even when you
connect the car battery the right way round.
Cause:
Touching the battery terminals several times when
making the connections can cause the charger's
micro-processor to "crash".
Remedy: Disconnect the battery clips, then re-connect them.
Fault:
You connect the NiCd battery, but the "START"
message does not appear in the display.
Cause:
The NiCd battery is deep-discharged.
Remedy: Press and hold the "Unterspannung" (low voltage)
button, then start the charge process by pressing
the "START" button.
COMPUTER-LADER MP 24 (DUO)
400 mA
-
+
red
black
receiver battery
4 or 5 NC cells
MP 24 DUO only!
BLACK = NEGATIVE (-)
-
Modellsport GmbH & Co. KG,
Fault:
The warning "FALSCHPOL!" (incorrect polarity)
appears in the display.
Cause:
The NiCd battery is connected incorrectly (reverse
polarity).
Remedy: Swap over the NiCd battery connections.
RED = POSITIVE (+)
Fault:
The rapid-charge process finishes shortly after you
press the "START" button, but the NiCd pack is still
in the discharged state.
Cause:
The battery is very deeply discharged.
Remedy: Repeat the charge starting process repeatedly whilst
holding the "Unterspannung" button pressed in.
Fault:
The rapid-charge process finishes, but the NiCd
pack is not fully charged and the warning message
"KFZ!" (car) appears in the display.
Cause:
The voltage of the car battery has fallen below 10.5
V. At this point the charger automatically interrupts
the rapid-charge process so that you can still start
your car engine.
CAUTION!
Disconnect the charger before you recharge the
car battery.
black
+
red
+
NiCd-battery
-
4 to 24 NC cells
black
Neuer Weg 2, D-75 223 NIEFERN
BLACK = NEGATIVE (-)
red
car battery
12 V
