Instructions for tapping a bore
through the vonRoll CLICK valve
Three variants of bore-tapping device are available for tapping the bore:
Variant 1
vonRoll universal bore-tapping
accessory
+ Connection piece no. 5
(universal bore-tapping accessory)
+ CLICK screw-on piece
Variant 2
vonRoll "Perfekt 2" bore-tapping
accessory, configuration 4
+ Connection piece
+ Click screw-on piece
Variant 3
HAWLE bore-tapping device
with Hawle ZAK
+ vRC lock ring
screw-on piece
®
Part no.
2" / 1 ½" 91502
G 1 ½"RH 33683
G 1 ½" LH, 33684
G 1 ½" RH
G 1 ½" RH 33683
G 1 ½" RH 33682
Fig.
7801
7813
-
