Please note the information on saw blade
types.
Any other use that is not expressly permit-
ted in this instruction manual may pose
a serious hazard to the user and result in
damage to the device. The operator or
user of the machine is responsible for any
accidents or personal injury and/or mater-
ial damage to third parties or their prop-
erty. The machine is intended to be used
by do-it-yourselfers. It was not designed
for heavy commercial use. The warranty
is void in the case of commercial use. The
manufacturer is not liable for damage
caused by improper use or incorrect oper-
ation.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material prop-
erly.
• Jigsaw
• 1 Wood saw blade T144D HCS,
Swiss made
• 1 Hex key
• Splinter guard (pre-assembled)
• Slide shoe (pre-assembled)
• Guard cover (pre-assembled)
• Suction nozzle (pre-assembled)
• Reducer piece
• Parallel guide
• Translation of the original instructions

Overview

The illustrations for the
device can be found on
the front and back fold-out
page.
1 Rotary wheel
2 Lock button
3 On/Off switch
22
4 Handle (Insulated gripping surface)
5 Hex key
6 Holder (Hex key)
7 Power cord
8 Reducer piece
9 Suction nozzle
10 Notch
11 Slide shoe
12 Switch (dust blower function)
13 Footplate
14 Hexagon socket screw
15 Pendulum stroke switch
16 Guide roller
17 Wood saw blade
18 Mount (Parallel guide)
19 Retaining screw
20 Guard cover
21 Chuck
22 LED work light (not visible)
23 Release (Chuck)
24 Button (LED work light)
25 Splinter guard
26 Recess in slide shoe
27 Parallel guide

Description of functions

With the jigsaw, the saw blade clamped
on one side cuts via a stroke movement.
With the pendulum stroke, the guide roller
moves the saw blade forwards during
every upstroke in addition to the vertical
saw movement.
Please refer to the descriptions below for
information on how the operating ele-
ments work.
