3.3 General maintenance
General maintenance should be performed after about 500 000 strokes or once
every three years. The tool must be completely disassembled and all seals and
worn parts must be replaced. This repair may be carried out by an authorized
technician only or a person trained by the manufacturer or supplier.
4. Spare parts 4. Spare parts
4.1 Ordering
Order the spare parts exclusively from the manufacturer or from your sales agent.
The order must contain:
A. tool serial number
B. number of ordered part
C. number of pieces
D. name of your company and precise address
E. your tax identification number and identification number
4.2 List of quickly expendable parts
Nosepiece no. 4 04D06400140
Nosepiece no. 5 04D06400150
Nosepiece no. 6 04D06400160
Nosepiece no. 6.4 04D06400164
Clamping sleeve 04D1100103
Set of 2-jaws 04D06301412 [being assembled till 8/2023 incl.]
Set of 3-jaws 04S1100153 [being assembled from 9/2023]
Conduit suction complete 04S1200502 [being assembled till 8/2023 incl.]
[strengthened version]
Conduit suction complete 04S1200503 [being assembed from 9/2023]
[strengthened version]
Scraper ring 04D1100300
Nut HP 04D1100400
Mandrel container 04S1201402
10
5. Storage 5. Storage
The pneumatic blind rivet tool embedded in a shipping container must be stored in
environment with relative humidity to 70% and temperature ranging from +5°C to
+40°C, without aggressive evaporation of salts, acids and caustics.
6. Complete tool equipment 6. Complete tool equipment
Replaceable nosepieces stored in the mandrel collector or in the carton box and
operations manual.
7. Operations and warranty conditions 7. Operations and warranty conditions
7.1 Operation conditions
For reliable function of the tool it is necessary to use treated compressed air.
Treated compressed air means compressed atmospheric air bare of solid particles
and water, reduced to required pressure and lubricated with anti-corrosive oil.
Immediately before the tool there must be a regulation valve set to maximum
outlet pressure of 0.7 MPa, air filter and lubrication in the circuit of compressed air.
Equivalent sound-pressure level of noise A, L
recommended to use ear protectors during continuous and long-term operation.
Aggregated weighted vibration acceleration level L
cumulative weighted effective value of the vibration acceleration a
The trigger enables safe control of the tool with a force max. 10 N < 50 N without
releasing the grip-handle according to the health regulation.
7.2 Warranty conditions
For reliable and safe function of the tool it is necessary to adhere to instructions
and principles stated above.
For the warranty period the customer must not perform any alterations other
than those permitted by the manufacturer, see paragraph 2.1, 3.1, 3.2. Other non-
detachable parts are secured with paint. In case of neglecting this protection, the
manufacturer shall not admit possible warranty repairs. To admit warranty, repair
the customer must submit confirmed proof of purchase [invoice]. The warranty
period is 24 months from the day of purchase if the purchase contract does not
state otherwise.
AS-2
. does not exceed 80 dB[A], still it is
pAeq,T
= 109,8 dB re 10 m.s . The
-6 -2
avw,T
= 0,309 m.s .
-2
vw,T
11
