Front & Rear Panel Descriptions –
1. Power Connector & Switch Connect the supplied AC
power cord to this jack. The power switch turns the mixer
on and off. The Power LED will illuminate when powered.
2. 48V Phantom Power Switch Provides 48V for mics,
affecting all XLR jacks simultaneously. The +48V LED
illuminates when phantom power is engaged.
3. XLR Inputs Connect a balanced mic or line-level signal
using an XLR connector.
4. Line Inputs Connect a balanced or unbalanced
line-level signal using a 1/4" connector.
5. Insert Connect a serial effects processor, such
as a compressor or gate, using a 1/4" Y cable.
6. 1/8" Input Connect an 1/8" line-level signal from
a smartphone, MP3 player, or other signal source.
7. Main Out L/R Connect to the inputs of amplifiers,
powered speakers, or a serial effects processor.
8. CR Out L/R Jacks and Knob Feed the inputs of a control
room amplifier, studio monitors or a headphone distribution
amplifier. The control knob controls the control output level.
9. Aux Mon, Mon Send & Master, Mon Mute / LED Feed stage
monitors via the mon send jacks. Each channel has its own
level control and the master adjusts the overall output level.
Engage the Mon Mute switch to mute the mon outs.
The button will illuminate red.
10. Aux FX, FX Send & Master, FX Mute / LED Feeds the internal
FX or an external processor via the FX send jack. Each channel
has its own level control and the FX master adjusts the overall
level sent out to the internal FX and FX outputs. Engage
the FX Mute switch to mute FX. The button will illuminate red.
11. FX Footswitch Connect a footswitch to mute or un-mute
the internal effects.
12. Phones Jack and Knob Connect stereo headphones here.
The phones knob controls the headphones level.
13. Gain Gain ajusts the mic/line input sensitivity.
14. Low Cut Switch Cuts bass frequencies below 100 Hz
at a slope of 18 dB per octave.
15. Line/Hi-Z Switch Engage the switch to play a guitar
through channels 1-2 without using a DI Box.
16. EQ Bypass Switch When engaged, the channel signal
bypasses the EQ.
17. Equalization Boost or cut the level at certain frequencies
to enhance the sound.
18. Pan Adjusts how much of the signal is sent to the left
and right outputs.
19. Mute Mutes the channel signal. The button illuminates
if the mute switch is engaged.
EN ES FR DE
20. Solo Switch Allows you to listen to individual channels singly
or in combination with other soloed signals. The rude solo LED
flashes when solo switches are engaged.
21. AFL/PFL Solo Switch Select between Pre-Fader Listen
[switch engaged] or After-Fader Listen [switch disengaged].
22. Solo Master Knob Adjusts solo volume levels to the control room.
23. Channel Fader Adjusts the level to the main mix. Turn it down
if the accompanying LED illuminates solid red.
24. Channel Assign Switch Assigns the selected channel to the main
out L/R.
25. FX / Mon Assign Switch Assign the FX and/or mon signals
to the main out L/R.
26. Main Mix Adjusts the level of the signal sent to the main outputs.
27. Main Meters Used to gauge the soloed input or output levels
to ensure that the signals are not clipping.
28. Main Mute Switch and LED Mutes all channel inputs,
but allows the USB inputs to pass out of the main outs.
The button illuminates if the mute switch is engaged.
29. FX to Mon Knobs Use these knobs to set the pre-fader level
of the FX return to the aux/mon mixes.
30. Bluetooth On/Off and Pair Switches Press the top button
to turn the Bluetooth channel on and off. Press and hold
to pair with a Bluetooth device. The Bluetooth may disconnect
when affected by Electrostatic Discharge [ESD].
Manually reconnect the Bluetooth connection.
31. Preset Selector and Display
Turn the preset selector to choose an effect. The display
shows the number of the currently selected effects preset.
32. FX Button Press this button to access the FX menu and control
FX-specific features.
33. SD Button Press this button to access and control
recording / playback and track selection.
34. Back Button Press this button to return to the previous screen.
35. SD Card Slot Insert an SD card to allow stereo
recording / playback of the main mix.
36. SD Transport Controls Press these buttons to rewind, fast forward,
play / pause and/or record files / tracks on the SD card.
37. SD Select Switch Engaging this switch mutes the input, allowing
the SD card return to flow through the channel instead.
38. Main USB Send Switch and LED Engaging this switch sends
the post-fader L/R signal to the USB 1/2 outputs instead
of channel 1/2.
39. USB 1/2 and 3/4 Switches Engaging this switch mutes the input,
allowing the USB return to flow through the channel instead.
40. USB I/O An interface allowing you to stream audio
to and from the mixer via computer.
9
Quick Start Guide
