Output Section - MIXVIBES U46MK2 Handbuch

U46MKII MIXVIBES
1 1 1 1

5.3. Output Section

2 2 2 2
(1) Output 1/2, 3/4, 5/6
You can individually change levels for all output channels by clicking and dragging the fader
bars. The number on the bottom shows the relative amount in dB. You can also select mute
button to mute each output channels
(2) Master Output
You can adjust all input / output monitoring levels by clicking and dragging the Master fader.
Again, the number on the bottom shows you the relative monitoring level in dB. You can also
select the mute button to mute all output channels.
17
