| EN |
PLC button
Duration of the
Action
button press
1 second LAN-Adapter: Start pairing with other devolo Magic
adapters
WiFi-Adapter: Start pairing with other devolo Magic
adapters; Start ConfigSync (Adapter receives Wi-Fi access
data from router)
> 10 seconds Reset devolo adapter to factory settings
PLC LED The devolo Magic WiFi mini adapter ...
... is working perfectly. It is connected to other devolo
Magic adapters.
... is currently establishing a pairing connection with
another adapter.
... is not connected to the network*
... is in standby mode.
... is currently undergoing a software update.
... has a poor Powerline connection.
... is currently in the start-up process.
... cannot see any other devolo Magic adapters.
... no longer has any LED function since it was disabled by
the user.
27
LED behaviour
Flashes white
Lights up red
LED behaviour
Lights up white
Quickly flashes white
Flashes red
Slowly flashes white
Alternately flashes white and red
Lights up white and then briefly
flashes red
Lights up red
None
Wi-Fi button
Duration of the
Action
button press
1 second WPS function is being carried out
(Adapter sends Wi-Fi access data to device)
> 3 seconds Wi-Fi is being switched off
Wi-Fi LED The devolo Magic WiFi mini adapter ...
... has a fault-free connection to the Internet.
... is attempting to establish a connection via WPS.
... no longer has any LED function since it was disabled by
the user.
* On page 43 you will see how to carry out manual pairing.
i Wi-Fi frequency range
This device uses only channels in the 2.4 GHz frequency range for Wi-Fi.
LED behaviour
Flashes white
LED goes out
LED behaviour
Lights up white
Flashes white
Off
