DUPLEX 340/420/620
GENERAL INFORMATION
4.2 DESCRIPTION OF THE COMPONENTS
1
Motor Protector
2 Handle
3 Detergent lever
4
Handle
5 Power cord
6 ABS detergent tank
7
Brush pressure regulator
8 Cover
9 Recovery tank
10 Brushes
11 Mop Up / Down
12 Transport wheels
13 Steam generator
14 Pump switch
15 Motor
16 Steam generator switch
17
Main switch
18 Safety handle (Start & Stop)
19 ABS water tank with filter
STAINLESS STEEL water tank with
20
filter
