8. Adhesive residue or other debris can
build up on the faces of the anvils
during use. To clean the anvils, place a
cleaning card or piece of paper inside
the closed anvils, and gently move
back and forth.
NOTE: Clean the anvils prior to turning on the gage, zeroing (pg.
6), or whenever the gage does not display -50 µm (-2.0 mils) when
replica tape is removed after taking a measurement.
After cleaning, power on the Testex Digital Micrometer by pressing
the button.
10. Press down on the lever to open the
micrometer anvils, and insert the
piece of replica tape, centering the
circular opening of the replica foam
between the anvils. Slowly release the
lever, allowing the anvils to gently
close on the replica.
Once the measured value stabilizes, the displayed value will flash,
and be recorded if Memory Mode is enabled (pg. 6).
NOTE: The gage should return to -50 µm (-2.0 mils) after the
replica tape is removed. If a different number is displayed after a
measurement is taken and the replica tape is removed, clean the
anvils as detailed above.
9. Ensure the correct grade of replica
tape is selected (pg. 1) and the H L
icon (pg. 7) is displayed at the bottom
of the screen.
NOTE: If using Coarse Minus grade
replica tape, H L mode should be
disabled. Any grade of replica tape can
be selected from the Menu.
