3.1.2. Connect to power supply

Boot the generator only under the following conditions.
Voltage:
Frequency:
Power consumption: < 30 V A
Temperature:
Humidity:
Plug the attaching plug into an AC 100 ~ 240 V outlet with grounding conductor, press the mains switch on
the panel in to turn on the generator. The generator now is initializing itself and obtaining the default
parameters, outputting sine waveform under continuous working state, with frequency and amplitude of the
signal displayed.
Warning!
In order to ensure the security of the operator, use triple- core socket outlet with grounding conductor.

3.2. Front panel

1. Power switch
2. Function keys
3. CHA output
4. CHB output
5. SYNC output
6. Arrow keys
7. Display screen
8. Number keys
9. Adjusting knob
AC 100 ~ 240 V
45 ~ 65 Hz
0 ~ 40°C
< 80 %
1.
7.
2.
-35-
9.
8.
3. 4. 5. 6.
