CONGA 9590 SPIN REVOLUTION ULTRA POWER Bedienungsanleitung Seite 37

ENGLISH
Quick cleaning modes
In addition, the robot vacuum cleaner already has pre-selected quick cleaning modes in which
you can define the cleaning area and settings and save your selection. In this way, by simply
selecting the quick cleaning mode you wish to use, the robot vacuum cleaner will automatically
clean as defined in that mode.
Other functions
Do not disturb function
A Do not disturb time slot can be configured to control the operation of the robot vacuum
cleaner; it can be modified or cancelled from the app. During the set time, the robot vacuum
cleaner will disable the automatic, continuous cleaning and timer functions.
Map editing function
- This function allows you to edit generated maps: rename cleaning areas, split or combine
areas, and edit cleaning mode, suction power, and scrubbing level in each selected area.
- You can also restrict areas by marking out specific areas on the map that you do not want
the robot vacuum cleaner to clean. You can select more than one restricted area on the
map.
Robot vacuum cleaner's Location function
Allows to locate the robot vacuum cleaner on the map.
4. CLEANING AND MAINTENANCE
Cleaning the main brush
The main brush spins at top speed and helps pushing the dirt into the suction mouth. This
brush is in contact with the floor, and therefore with dirt, so it can wear out overtime, affecting
negatively to the cleaning efficiency. It is therefore recommended to replace the main brush
after approximately 250 hours of use.
1. Slightly press the main brush frame's tabs to open the main brush compartment and
remove it. Fig. 9
2. Remove hair, lint, and other dirt trapped in the brush and around the shafts with the
help of the self-cleaning brush. Fig. 10
3. Clear and clean the robot vacuum cleaner's suction channel.
4. Reinstall the main brush and its frame.
Recommendation
It is recommended to clean the main brush once a week with the help of the self-cleaning
brush.
72
CONGA 9590 SPIN REVOLUTION ULTRA POWER
Side brush. Fig. 11
The side brush is designed with many bristles that push dirt into the suction mouth and
thoroughly clean edges and corners. This brush may wear out overtime, which will negatively
affect cleaning efficiency. We recommend replacing the brush every 3 months (depending on
the frequency and type of use).
Recommendation
- It is recommended to clean the side brush once a week with the help of the self-cleaning
brush.
- Remove the side brush by pulling it outwards and clean it regularly.
Mixed tank. Fig. 12:
- Remove the mixed tank.
- Empty the water tank
- Open the mixed tank cover and empty it.
- Remove the filter and filter holder as shown in Figure 14.
- Use the self-cleaning brush to clean the inside of the mixed tank.
- Reinstall the mixed tank on the robot vacuum cleaner.
High-efficiency filter. Fig. 13:
- The high-efficiency filter is designed with fibres that help trap dust particles, dust mites,
pollen... It is very important to periodically clean the filter, to prevent these particles
from building up in the filter, causing efficiency loss. It is convenient to carry out this
maintenance once a week.
- Replace the high efficiency filter every 3 months, depending on the frequency and type of
use.
Recommendation
You can remove dirt from the high-efficiency filter with a small brush or gently shake the filter
on a hard surface to remove the dust. The high-efficiency filter cannot be washed.
Primary mesh filter and sponge filter
The filtering system is featured with a primary mesh filter and a sponge filter, located next to
the high-efficiency filter. It is suggested to replace them either after a maximum of 160 hours
of use or when they are worn out due to operation.
Recommendation
Dirt can be removed with a small brush or by shaking carefully against a hard surface for dust
to fall off. You can also use warm water without detergents to obtain better results. Always
make sure they are completely dry before installing them again; otherwise, moisture can reach
the robot vacuum cleaner's motor and damage it.
ENGLISH
CONGA 9590 SPIN REVOLUTION ULTRA POWER
73
