K IT PART S
1. Internal support
2. Long support
A
ST6x60mm screw (x4)
B
Wall plug (x4)
FAC ILIT Y
1. Mark the 4 holes on the wall that
you need to make with the drill. The
horizontal separation between the upper
holes must be 392 mm, the lower ones
450 mm and vertically 936 mm.
4. Attach the internal supports and the 2
front accessories to the towel rack with
the screws and nuts, then attach the
decorative cover so that the screw is not
visible.
E NGL I SH
8
3. Short support
4. Top
5. Front accessory
6. Nut
C
M6x40mm screw (x2)
D
M4x12mm screw (x4)
2. Once the holes have been marked, drill
the 4 10mm diameter holes.
3. Insert the plug into the hole in the wall.
Then attach the short and long bracket
using the wall screw to secure it prop-
erly. Repeat the step in the rest of the
holes.
7. Towel rail
Top holes
Bottom holes
