Taconova TACOFLOW3 MAX Kurzanleitung Seite 10

TACOFLOW3 MAX / MAX PRO
INFORMATION ABOUT THE QUICK GUIDE AND WARNINGS
THIS GUIDE IS AN INTEGRAL PART OF THE "INSTALLATION AND USE INSTRUCTIONS" MANUAL
WHICH IT REFERS TO. IT PROVIDES AUTHORISED MAINTENANCE TECHNICIANS (MECHANICAL,
HYDRAULIC AND ELECTRICAL) WITH A QUICK CONSULTATION OF THE "ILLUSTRATED INSTRUCTIONS"
TO INSTALL THE CIRCULATOR.
THE INSTALLATION OF THE CIRCULATOR CAN ONLY BE CARRIED OUT BY THE
MECHANICAL AND HYDRAULIC MAINTENANCE TECHNICIAN AND THE ELECTRICAL
MAINTENANCE TECHNICIAN (SEE PAR. 2.4).
BEFORE CARRYING OUT ANY WORK ON THE CIRCULATOR, AUTHORISED MAINTENANCE
TECHNICIANS (MECHANICAL, HYDRAULIC AND ELECTRICAL) MUST USE THE INTENDED PERSONAL
PROTECTIVE EQUIPMENT (PPE) (SEE CHAP. 8).
BEFORE USING THE CIRCULATOR, IT IS MANDATORY FOR THE AUTHORISED OPERATORS TO
READ AND BE CERTAIN TO HAVE UNDERSTOOD ALL THE PARTS OF THE "INSTRUCTIONS FOR
INSTALLATION AND USE" MANUAL.
IT IS FORBIDDEN TO HANDLE THE CIRCULATOR BY GRASPING
THE HEAT SINK (REF. 1): THE ELECTRONIC BOARD CAN BE
DAMAGED (SEE PAR. 9.2).
CONTENTS OF THE FIGURES
FIG. 1 - Suitable liquids for the use and operating
temperatures
FIG. 2 - Suitable tools for installation
FIG. 3 - Insulating shells
FIG. 4 - 5 - Mounting positions
FIG. 6 - Motor body position
FIG. 7 - 8 - Mounting the pipes
PACKAGING AND PACKAGING CONTENTS
Generally, the circulator is delivered assembled and fitted in a cardboard box.
Parts of the circulator
1 Circulator
2 Gaskets
10
| Quick Guide
ATTENTION
INFORMATION
REFERENCES TO PARAGRAPHS OR CHAPTERS IN THE GUIDE ARE INDICATED AS FOLLOWS:
• IN THE TEXT WITH "SEE PAR. XX / V. CHAP. XX"
• IN THE FIGURES WITH "SYMBOL AT THE SIDE" (XX = CHAPTER).
WARNING
WARNING
DANGER
DANGER
FIG. 9 - Mounting insulating shells
FIG. 10 - Electrical connection
FIG. 11 - Start-up
FIG. 12 - Venting the system
FIG. 13 - Operating mode
FIG. 14 - Setting the circulator to MAX PRO mod.
FIG. 14 - Setting the circulator to MAX mod.
2 Insulating shells
1 Connector (L - N -
1 Quick installation guide
)
