LED Rechargeable Battery Pocket Light
EN
PRO
Many thanks for choosing our product. With the following lnstructions, we would like to
help you to get the best functions of your new light. Keep this instruction manual for future
reference or for subsequent possessors.
Technical Data
Degree of protection
Operating temperature
Lamp
Light source
Luminous power
Operating time
Battery specification
Charging time
Charging input
Warning
Do not open the device.
■
Do not look directly into the light emitting lamp - Risk of eye injuries!
■
Do not operate in direct sun light or extreme temperature conditions.
■
Operating temperature, -10 °C to +40 °C.
■
Keep away from children! Children should be supervised in order to ensure that they do
■
not play with the device!
Operating & Charging Procedure
WL6003 operating mode as below
Press the Switch first time, top light switches on.
■
Press the Switch second time, main light will switch to ECO mode.
■
Press the Switch third time, main light will switch to full power mode.
■
Press the Switch fourth time, whole light will switch to switch off.
■
Switch lamp off and connect with USB charger during charging.
■
The LED of the indicator switches to green blinking due to ring charging.
■
When the charging is completed, green LED will turn on. lf the battery indicator did not
■
light up, please remove the charger and try again.
Always only use the charger recommended to charge the lamp. The use of
■
a NON-recommended charger can lead to a fire and destroy the lamp.
IP65, IK07
-10 °C to +40 °C
high power COB LED- Main light
high power SMD LED- Top light
approx. 600 Im - Main light full power mode
approx. 150 Im - Main light ECO mode
approx. 250 Im - Top light
approx. 3h - Main light full power mode
approx. 8h - Main light ECO mode
approx. 8h - Top light
Li-Ion 3.7 V, 2600 mAh, 9.62 Wh
ca. 4 h
DC 5 V 1A
