Remote:
1. Upshift for gearbox
2. Downshift for gearbox
3. Gearbox mode selection (Auto - Manual)
Long press: Reverse (Optional on defined
bikes)
4. Throttle (Boost & Walk assist)
Main screen elements:
1. Current speed
2. Distance
3. Gear engaged
4. Walk assist
5. Assistance mode
6. Unit selected (KM/H or MPH)
7. Battery state of charge indicator
8. Light status
9. Maintenance logo
10. Lock mode
11. Bluetooth status
TECHNICAL DAT A
Model
SKU display
SKU display mount
Protection rating
Screen size
8
View Plus
654200
654201
IP65
40 x 40 mm
OPERATING INSTRUCTIONS
The power of the View Plus display is supplied by the Valeo e-bike
system battery.
Please read the battery, charger and the Valeo Cyclee™
mobile app user manual before using the View Plus display.
Switching the system On
To switch the e-bike system On you may briefly press the On/Off button
on the display. If your Valeo Cyclee™ System is in lock mode you may
need to enter a pin code or unlock the e-bike via the Valeo Cyclee™
mobile app. Please refer to the lock mode section below.
You can also turn the e-bike system On by pressing the On/Off button
of the battery.
Switching the system Off
A short press on the On/Off button will simply turn the system Off,
when a long press will turn the system Off and put it in lock mode.
If no energy is drawn from the e-bike system for some time and the
e-bike is not moving the system will shut off on its own.
Always switch the system/battery Off before removing or
installing the battery onto the e-bike.
Lock mode
The lock mode is the anti-theft function of your Valeo Cyclee™ system.
Before using the lock mode for the first time you need to enable
this function in your Valeo Cyclee™ mobile app.
When in lock mode the electrical assistance is automatically shut-off
and the integrated gearbox switches in neutral position without any
possibility to crank.
