Simplified
error Component Error name Potential root
code
E0509 Under Temperature of
temperature the motor is too
error cold
E0510 Internal system System is facing
error an internal error
MOTOR
E0511 Torque sensor Issue detected
error on Torque
Sensor
E0201 Charging error Issues with
external battery
charger or plug
connections
E0202 Communication Communication
error error with motor
or external
device
E0203 Electrical error Battery voltage
BATTERY
or current error:
- Battery cells
under / over
voltage or
unbalanced
- Battery
overcurrent
E0204 Internal error Internal error
E0205 Temperature Temperature of
error the battery is
too high or too
cold
24
System Action/Solution to
Description
operating solve the issue
restriction / Troubleshooting
cause
limitation Corrective action
No assistance Go back to nominal
anymore, temperature (ambient
gearbox shifting temperature).
can also be If the issue is still
impacted present, go to your
repairer.
No assistance Restart the system.
anymore If the issue is still
present, go to your
repairer.
No assistance Restart the system.
anymore If the issue is still
present, go to your
repairer.
Battery will no Check connections
longer charge between bike battery
& charger disconnect/
reconnect the charger
on the battery.
Check electrical
supply to the wall plug.
Check connections
between charger &
wall plug disconnect/
reconnect the charger
on the wall plug.
Check external battery
charger itself
If the issue is still
present, go to your
repairer.
System will cut Remove and reinstall
off (urgent or battery, restart system.
nominal cut off) If the issue is still
present, go to your
repairer.
System will cut Check the battery for
off (urgently or external damages.
after 1.5s) Restart the system.
Try a battery charging
cycle at ambient
temperature.
If the issue is still
present, go to your
repairer.
System will cut Restart the system.
off If the issue is still
present, go to your
repairer.
System will cut Go back to battery
off nominal temperature
(battery should rest at
ambient temperature).
Restart the system.
If the issue is still
present, go to your
repairer.
Simplified
error Component Error name Potential root
code
E0301 Button blocked Issue on display
or remote
button switches
E0302 Communication Communication
error error with motor
E0303 Remote Electrical issues
electrical error on remote
E0304 Internal error Internal
DISPLAY
electrical issue
on display
E0305 Temperature Temperature
error of display is
too high or too
cold or issue on
temperature
measurement
E0306 USB error Over current
intensity on the
USB port
System Action/Solution to
Description
operating solve the issue
restriction / Troubleshooting
cause
limitation Corrective action
Only gearbox Check that buttons
automatic aren't damaged or
shifting is blocked.
enabled. Throttle If the issue is still
is disabled. present, go to your
repairer.
System will cut Check connectors
off (nominal cut between motor &
off) display.
Restart the system.
If the issue is still
present, go to your
repairer.
Manual gearbox Check connections
shifting & Boost between display &
mode & Walk deported box. Restart
Assist disable the system. If the issue
is still present, go to
your repairer.
Display screen Restart the system.
not functional If the issue is still
present, go to your
repairer.
USB port disable Go back to
display nominal
temperature. (ambient
temperature).
If the issue is still
present, go to your
repairer.
USB port disable Check USB port
(Cleanliness...).
Check USB external
device & cable isn't
damaged.
Try to disconnect/
reconnect the USB
external device.
If the issue is still
present, go to your
repairer.
