LED light
5
Digital pressure gauge with air pressure display (not trade-approved) and battery display
6
Power switch for the power bank
7
Menu button "M"
8
Car jumpstart outlet
9
"–" button
10
Charging port 5 V
11
USB port 5 V
12
USB port 5 V
13
Bars for battery level
14
Storage compartment for the valve adapters
15
Hose connection
16
Compressed air hose
17
Jump lead
18
Green Start LED
19
Red Error LED
20
Valve adapter for balls
21
Valve adapter for inflatable items
22
Valve adapter for inflatable items
23
USB cable
24
PLEASE NOTE: The use of the term 'product' or 'device' in the following text refers to the power
bank with compressor named in these operating instructions.
z Technical Specifications
The four individual cells used to construct the rechargeable battery pack are connected in series to produce
a total voltage of 4 × 3.2 V ≈ 12 V and a capacity of 3500 mAh. The battery output produced in this way
is the same as the output from a rechargeable battery pack with a total capacity of 14000 mAh at 3.2 V.
Model:
Battery type:
Battery, chemical system:
Battery capacity:
8
GB/IE/NI/CY/MT
/2 A (USB-C)
/1 A (USB-A)
/2 A (USB-C)
UPK 10 H5
Lithium Iron Phosphate rechargeable battery pack
(F8043126)
Lithium Iron Phosphate (LiFePO4)
14000 mAh, 3.2 V , 44.8 Wh
