This allows you to identify problem areas immediately
before first use and correct them if necessary.
The same procedure is recommended for critical
places, such as embankments/ditches/beds, etc.
Proceed as described above and start the mower
(see point 9) with the "START" button.
In the event of a problem, you can stop the mower by
pressing the stop button (4) on the product.
9. Starting up / adjustments
m ATTENTION!
To ensure optimum function, a software update
must be carried out before first use. (see 13.3
Software update)
m NOTE
For a long service life, the robot mower (1) should
only be operated at an outdoor temperature of 5 - 40
°C.
m ATTENTION!
Always make sure the product is fully assembled
before commissioning!
Electrical connection
The electrical motor installed is connected and ready
for operation. The connection complies with the ap-
plicable VDE and DIN provisions.
The customer's mains connection as well as the ex-
tension cable used must also comply with these reg-
ulations.
Damaged electrical connection cable
The insulation on electrical connection cables is of-
ten damaged.
This may have the following causes:
• Pressure points, where connection cables are
passed through windows or doors.
• Kinks where the connection cable has been im-
properly fastened or routed.
• Places where the connection cables have been cut
due to being driven over.
• Insulation damage due to being ripped out of the
wall outlet.
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not
be used and are life-threatening due to the insulation
damage.
Check the electrical connection cables for damage
regularly. Ensure that the connection cables are dis-
connected from electrical power when checking for
damage.
Electrical connection cables must comply with the
applicable VDE and DIN provisions.
Only use connection cables of the same designation.
The printing of the type designation on the connec-
tion cable is mandatory.
9.1. Quick start (Fig. 19/20)
After installing the boundary wire (11), you can use
the robot mower (1).
Adjusting the cutting height
• Turn the cutting height adjustment knob (2) clock-
wise to increase the cutting height seamlessly be-
tween 20 - 60 mm.
• Turn the cutting height adjustment knob (2) an-
ti-clockwise to decrease the cutting height seam-
lessly between 20 - 60 mm.
m NOTE
The arrow on the cutting height adjustment knob (2)
points to numbers outside the knob. Here you can
read off the cutting height currently set in 5 mm steps.
Halting/stopping the robot mower:
• To stop the robot mower, press the stop button (4).
• The robot mower stops immediately and the blade
disc (6) stops.
m ATTENTION
The robot mower is not switched off, it has only been
stopped. Always use the "POWER ON/OFF" button
to switch the robot mower off.
Switching the robot mower on:
• The robot mower can then be restarted as de-
scribed below.
m NOTE
Before the robot mower (1) starts mowing, an acous-
tic signal (four beeps) is heard, then the blade disc (6)
starts rotating.
• Press the
til the robot mower (1) switches on.
• For the first use, enter the default PIN code "0000"
by pressing "OK" four times when the number "0"
flashes. (The PIN code can be changed as de-
scribed in point 9.2.1).
• After confirming the fourth digit with the "OK but-
ton", the robot mower is ready for use. The word
"IdLE" appears on the display.
m NOTE
The robot mower (1) switches off automatically after
30 seconds if no input is made.
www.scheppach.com
button ("POWER ON/OFF" button) un-
GB | 29
