4.8 Ablaufdiagramm auto stop mode
auto stop mode
start by push button
WIPER READY
output 2 = low
output 3 = high
MOVE
in XY to
cleaning position
START CLEANING
MOVE in Z to
cleaning position
POSITION
REACHED
outpu 4 = high
tape move
preset length
CLEANING
FINISHED
output 3 = high
nozzle cleaned
proceed with
dispensing
8
Bedienungsanleitung Wiper I
auto stop mode
start by external signal
WIPER READY
output 2 = low
output 3 = high
MOVE
in XYZ to
cleaning position
START
CLEANING
input 1 = high
tape move
preset length
CLEANING
FINISHED
output 3 = high
nozzle cleaned
proceed with
dispensing
