FPA-1200
Short Description
Featuring the well-known LSN bus technology, the FPA-1200 Fire Panel monitors small and
medium-sized objects. 1 loop or 2 loops can be implemented with up to 127 elements each.
The configuration is set with the FSP-5000-RPS Programming Software on a laptop.
Via the FPA-1200-MPC Panel Controller the fire panel and all peripherals are controlled and
operated. Every incoming fault or alarm message is stored by the Panel Controller and can be
displayed and processed at any time.
See Figure 3, Page 4 for a basic system overview.
Features
-
-
-
-
Installation and Configuration Notes
-
-
-
-
-
-
NOTICE!
i
For detailed information about the installation and configuration, please refer to the manuals
included in every single component delivery.
Parts Included
QTY
Scope of delivery see also Figure 1, Page 3.
Technical Data
Operating voltage
Display unit
Operating unit
Max. loop length
Dimensions (W x H x D)
Weight
Permissible operating temperature
Permissible storing temperature
Protection class as per IEC 60529
Bosch Sicherheitssysteme GmbH
Connection to the Building Integration System BIS via an OPC server
Remote operation by up to 3 FMR-5000 Remote Keypads
Interface to Bosch Voice Evacuation System Plena
Plug-in and auto-detection of modules during operation
Panel networking and redundancy is not feasible.
The installation of an LSN 1500 A module is not provided for.
Each loop requires 1 LSN 0300 A module.
A maximum of 2 LSN 0300 A modules, or 2 loops respectively, is feasible.
Each loop allows the maximum connection of 127 elements.
Up to 6 functional modules can be plugged in.
CTN
1 FPA-1200-MPC
1 LSN 0300 A
1 BCM-0000-B
1 PRS 0002 A
1 PRD 0004 A
1 UPS 2416 A
1 HCP 0006 A
1 FPO-5000-PSB-CH Power Supply Bracket
3 FDP 0001 A
1 FSP-5000-RPS
Designation
Panel Controller
LSN improved Module 300mA
Battery Controller Module
Panel Rail Short
Panel Rail Long
Universal Power Supply
Panel Housing for 6 Modules
Dummy Cover Plate
Programming Software on CD (included in delivery of FPA-1200-
MPC Panel Controller)
20 V DC to 30 V DC
5.7" LCD display
Touch screen
1600 m
638 mm x 440 mm x 149 mm
(25.1 x 17.2 x 5.87 inch)
Approx. 20 kg (44 lb)
-5 °C to +50 °C
-20 °C to +60 °C
IP 30
