eta 0706 Bedienungsanleitung Seite 14

GB
Mode on/switch button control A1
When you press the button once, the brush switches on in mode C. If
you press the button again within 5 seconds, the brush will switch to
mode S. If you press the button repeatedly within 5 seconds, the brush
will switch to mode W. If you press the button repeatedly within
5 seconds, the brush will switch to mode M. When you press the button
again, the brush will switch off. The brush will also switch off if you press
the button A1 in mode C/S/W after 5 seconds after its activation.
Cleaning modes:
1) "C" – CLEAN mode (blue light A2 is on)
– standard intensive mode for regular cleaning of healthy teeth.
2) "S" – SOFT mode (green light A2 is on)
– gentle mode for sensitive teeth or mouth parts; recommended in case
of increased sensitivity of teeth.
3) "W" – WHITEN mode (red light A2 is on)
– cleaning mode adapted for better teeth whitening,
4) "M" –MASSAGE mode (blue light A2 is flashing)
– pulse mode for gentle gum massaging.
Activation of the mode selected is indicated by the indicator A2 coming on.
IV. CLEANING AND MAINTENANCE
For maximum hygiene, clean the brush B after each use! Rinse the
brush head B1 and the brush body A under running water and wipe the
brush body with a damp cloth. Use the damp cloth to wipe the charging
base and its cable as well. Never immerse the brush body A in water! Do
not use a dishwasher for cleaning! Allow the brush body A to dry properly
before re-use. Store the appliance and all the accessories in a dry, dust-
free and safe place, out of reach of children and incapacitated persons.
V. ENVIRONMENTAL PROTECTION
If the dimensions allow, there are labels of materials used for production
of packing, components and accessories as well as their recycling on
all parts. The symbols specified on the product or in the accompanying
documentation mean that the used electrical or electronic products must
not be disposed of together with municipal waste. For proper disposal of
the product, hand it over at special collection places where it will be taken
over free of charge. Suitable disposal of the product can help to maintain
valuable natural resources and to prevent possible negative impacts on the
environment and human health, which could be the possible consequences
of improper waste disposal. Fines can be imposed for improper disposal
of this type of waste in agreement with the national regulations. This
appliance is equipped with Li-ion batteries with a long service life. For
environmental protection it is necessary to remove the battery from the
appliance after its service life and the battery and the appliance must be
disposed of safely using special collection networks. Ask for more details at
the local authority or at the local waste collection site.
Removing the battery
Remove the battery from the appliance only when completely discharged
(i.e. leave the appliance running until it stops).
The procedure for removing the battery is shown in Fig. 5:
1. Using a screw-driver, remove the screw cover and loosen the screw.
2. Hold the brush body A upside down, press the charging part (see
arrows in the figure) and remove the 2 hooks which hold the inner
components of the brush body (A).
3. Remove the battery from the compartment using a screw-driver.
VI. TECHNICAL DATA
Voltage (V)
Weight (kg) approximately
Size, (mm):
Noise level: Acoustic noise level of ≤ 65 dB(A) re 1pW.
The manufacturer reserves the right to change the technical
specifications and accessories for the respective models. Expert
service must do the large maintenance or to intervene into inside
parts of the appliance! Non-observance of the instructions of the
manufacturer cancels the right for guarantee repair!
HOUSEHOLD USE ONLY; DO NOT IMMERSE IN WATER OR OTHER
LIQUIDS;
NOTICE
- Removable power supply unit
shown on the type label of the appliance
TO AVOID DANGER OF SUFFOCATION, KEEP THIS
PLASTIC BAG AWAY FROM BABIES AND CHILDREN.
DO NOT USE THIS BAG IN CRIBS, BEDS, CARRIAGES
OR PLAYPENS. THIS BAG IS NOT A TOY.
- Please read the instructions manual
14 / 29
0.11
180 x 27 x 27
