• Keep batteries away from children. Children can put
All manuals and user guides at all-guides.com
batteries into their mouths and swallow them. If a battery
is swallowed immediately seek medical assistance.
Technical data
Electricity supply:
Measurement range:
Measurement accuracy: +/- 1%
Laser class:
Wavelength ( ):
Output level (P max.):
Items supplied
• Ultrasonic Distance Meter
• 9 V Block battery
• Operating Instructions
Unpacking
Remove the Ultrasonic Distance Meter from the packaging.
Remove all transport restraints and packaging materials.
Remove the protective foil from the display w.
Device description
1 Laser emission opening
2 Ultrasonic sender/receiver
3 Temperature sensor
4 FT/M button
5 RECALL button
6 Measurement point
7 Battery compartment
8 Spirit level
9 MODE button
0 ON/OFF button
q READ button
w Display
9 V Block battery, 6F22/6LR61
0.6 - 16 m
2
650 nm
< 1mW
- 52 -
