All switches positioned to the left:
• Switch 1+2, combined floor/room sensor. (NC and NC)
• Switch 3, control as a normal thermostat. (HT)
• Switch 4, limit against too high temperature. (HI)
The temperature limit potentiometer has been set at
approximately 34 degrees in the example above.
Potentiometer
Room Sensor
Switches
