Grundfos AUTOADAPT Montage- Und Betriebsanleitung Seite 7

Two-pump installation without CIU box
5 5
1
Position Description
1 Rotary power switch
2 Terminal box
3 Relay 230 V
4 Indicator light (LED)
5 Earth leakage circuit breaker (16 A)
6 Earth leakage circuit breaker (10 A)
6
4
3
2
Pieces
1
1
1
1
2
1
Two-pump installation with CIU box
5 5
1
2
Position Description
1 Rotary power switch
2 Terminal box
3 Relay 230 V
4 Indicator light (LED)
5 Earth leakage circuit breaker (16 A)
6 Earth leakage circuit breaker (10 A)
7 CIU 902
6
4
7
3
Pieces
1
1
1
1
2
1
1
7
