8. Dimensional drawings

8.1 MNX 125

B1
C
A
A B2
B1
Fig. 1 MNX 125 enclosure
A B1 B2 C Mounting holes IP class
MNX 125
[mm] [mm] [mm] [mm] [mm] -
∅4.5
130 60 125 113.5 x 113.5 IP66 / IP67
10
