2.2 Product setup

One-pump installation without CIU box
5 6
1
2
Position Description
1 Rotary power switch
2 Terminal box
3 Relay 230 V
4 Indicator light (LED)
5 Earth leakage circuit breaker (16 A)
6 Earth leakage circuit breaker (10 A)
6
4
3
Pieces
1
1
1
1
1
1
One-pump installation with CIU box
5 6
1
2
Position Description
1 Rotary power switch
2 Terminal box
3 Relay 230 V
4 Indicator light (LED)
5 Earth leakage circuit breaker (16 A)
6 Earth leakage circuit breaker (10 A)
7 CIU 902
4
7
3
Pieces
1
1
1
1
1
1
1
