This warranty shall be valid to the extent aforementioned and
under the above-named circumstances (including the sub-
mittal of the original proof of purchase also in case of resale)
for any future owner of the product.
Declaration of conformity
Stadlbauer Marketing + Vertrieb GmbH hereby declares
that this model including the controller conforms with the
fundamental requirements of the following EC directives:
EC Directives 2009/48 and 2004/108/EC regarding electro-
magnetic compatibility and the other relevant regulations of
Directive 1999/5/EC (R&TTE).
The original declaration of conformity can be requested from
carrera-rc.com.
Maximum radio-frequency power transmitted <10 dBm
Warning!
A remote-controlled Quadrocopter is NOT A TOY and is
only suitable for teenagers over the age of 14!
This product is not intended for use by children without
supervision of a parent. Flying the Quadrocopter requires
skill and children must be trained under the direct supervi-
sion of an adult. Read the user's information together with
your child Before the first use. Inappropriate use may result
in severe injuries and/or damage to property.
It has to be operated with care and caution and requires both
mechanical and mental skills. The operating instructions
contain notes on safety and technical regulations as well as
information on maintaining and operating the product. It is
indispensable to read these instructions thoroughly before
the first usage. Only this helps to avoid accidents with inju-
ries and damage.
Only use the Quadrocopter in closed rooms which pro-
vide sufficient space and follow all instructions given
in this manual.
Hands, hair and loose clothing, including other objects such
as pens and screwdrivers must be kept away from the pro-
peller (rotor). Do not touch the rotating rotor. Especially take
care that your hands DO NOT get close to the rotor blades!
WARNING: Risk of eye injuries. Do not fly near your face
to avoid injuries.
As user of this product you are solely responsible for
handling it safely in order to ensure that neither you nor
other persons or their property suffer damages or are
endangered.
• Never use your model with weak remote control batteries.
• This toy is only designed to be used in a home environment.
• WARNING: Do not start up and fly when persons,
a nimals or any obstructions are within the flying range
of the Quadrocopter.
• Exactly observe the instructions and warnings for this
product and for any possible additional equipment (battery
charger, rechargeable batteries etc.) being used by you.
• Should the Quadrocopter come into contact with any
living thing or solid object, immediately return the gas
control to zero, in other words the left-hand joystick
must be at the stop at the bottom of the slide!
• Avoid any moisture as this might do damage to the elec-
tronics.
• Do not change or modify anything on the Quadrocopter.
If you do not agree to these terms please immediately return
the complete Quadrocopter model in new and unused condi-
tion to the retailer.
Important information concerning Lithium Polymer
rechargeable batteries
Lithium-Polymer (LiPo) rechargeable batteries are sig-
nificantly more sensitive than traditional alkali- or NiMH-re-
chargeable batteries normally used with radio control units.
Therefore the instructions and warnings have to be observed
in detail. In case of improper use of LiPo rechargeable batter-
ies there is a danger of fire. Always follow the manufacturers´
instructions if you dispose of LiPo rechargeable batteries.
Regulations on disposal for waste electrical and elec-
tronic equipment (WEEE)
This symbol, showing refuse bins with
a cross through them, denotes that
empty batteries, rechargeable batter-
ies, button cells, recharge able battery
packs, equipment batteries, disused
electrical equipment, etc. should not be disposed of in do-
mestic refuse, as they are harmful to the environment and
health. Please help to preserve environment and health and
talk to your children about the correct disposal of used bat-
teries and disused electrical equipment. Batteries and dis-
used electrical equipment should be handed in to the usual
collection points where they can be properly recycled.
Do not mix dissimilar battery types or employ new and used
batteries together. Empty batteries should be removed from
the product. Do not attempt to recharge non-rechargeable
batteries.
WARNING!
Rechargeable batteries should only be charged under adult
Never leave the battery unattended while it is
supervision.
charging. Exhausted batteries are to be removed from the
toy. Rechargeable batteries should be removed from the prod-
uct before charging. Supply terminal are not to be short-circuit-
ed. Only use the batteries recommended or equivalent types.
If in regular use the charger must be examined for damage
to the cord, plug, covers and all other parts. If any signs of
damage are found the charger may only be used again after
repair work has been completed.
The toy is only to be connected to Class II equipment bear-
ing the following symbol.
FCC statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, in-
cluding interference that may cause undesired operation.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
Guidelines and warnings for the use of LiPo recharge-
able batteries
• You have to charge the attached 3.7 V
rechargeable battery in a safe place and at a safe distance
to flammable material.
• Never leave the battery unattended while it is charging
• After a flight, the rechargeable battery has to cool down to
the ambient air temperature before charging it.
• You must always use the corresponding LiPo charging unit
(USB cable / remote control). In case of non-compliance
with these directions there is a danger of fire resulting in
a health risk and/or damage to property. NEVER use any
other battery charger.
• Should the rechargeable battery swell or deform while
discharging or recharging, you have to immediately stop
charging or discharging the battery. Take the battery out
as quickly and carefully as possible and place it in a safe
and open area offside any inflammable material and watch
it for at least 15 minutes. In case you continue charging or
discharging a battery which has already started to swell
or deform there is a danger of fire! Even in case of slight
deforming or ballooning the rechargeable battery has to be
taken out of operation.
• Store the rechargeable battery at ambient temperature in a
dry place.
• Always recharge the battery immediately after use to
prevent its becoming deep discharged. Please make
sure to allow a pause of about 20 minutes between fin-
ishing the flight and recharging the battery. Recharge
the battery occasionally (suggested every 2-3 months).
Failure to treat the battery as described above can lead
to its becoming defective.
• When transporting or temporarily storing the rechargeable
battery the temperature should be between 5-50°C. If pos-
sible, do not store the battery or the model in a car and do
not expose it to direct sunlight. In case the battery is broiled
it can be damaged or catch fire.
Note: If the battery voltage/output is low you will recognise
that a considerable trim and/or controlling is necessary to
avoid that the Quadrocopter starts trundling. This usually
occurs before reaching a battery voltage of 3 V and it is a
good moment to end the flight.
7
Contents of package
1 x Quadrocopter
1
1 x Controller
1 x USB charging cable
1 x Set of replacement parts
4 x 1.5 V Mignon AA batteries
(non-rechargeable)
Recharging the LiPo rechargeable
battery
Make sure you only charge the LiPo rechargeable battery
supplied with the LiPo charging unit also supplied (USB ca-
ble and remote control). If you try to charge the rechargeable
battery with a different LiPo battery charger or any other bat-
tery charger, this might cause serious damage. Please care-
fully read the previous chapter with warnings and guidelines
on the usage of rechargeable batteries before proceeding.
Supply terminals are not to be short-circuited.
The rechargeable battery fitted in the Quadrocopter with its
USB charging cable can be charged either from a USB port
on a computer or directly from the remote control:
• Connect the USB charging cable with the USB
2
port of a computer
The LED on the USB charger cable lights green
indicating that the charger unit is correctly con-
nected to the computer or the controller. If you
plug in a Quadrocopter with a discharged battery,
the LED on the USB charging cable no longer
lights up, showing that the Quadrocopter battery
is being charged. The USB charging cable and
the charging socket on the Quadrocopter are de-
signed to make incorrect connection impossible.
• It takes about 30 minutes to recharge a dis-
charged battery (but NOT a deep-discharged
one). When the battery is fully charged, the
LED display on the USB charger cable lights up
green again.
Note: when supplied, the lipo-battery is already partially
charged. So the first charging cycle may well take less time.
It is essential to follow the connection sequence given
140 mAh LiPo
above!
While charging, the power switch must be in the "OFF"
position.
Inserting the batteries in the
remote control
Open the battery compartment with a screwdriver
3
and insert the batteries in the remote control.
Please keep in mind the correct polarity. After
having closed the compartment you can check all
functions of the remote control with the help of the
power-switch on the front.
With the power switch turned ON and functioning
correctly, the top centre LED on the remote con-
trol will light up red.
When the control LED flashes rapidly, the batter-
ies in the controller must be changed.
Frequency bind between model
and remote control
The Carrera RC Quadrocopter and the remote control are
frequency bound at purchase. If initially there are any prob-
lems with communication between the Carrera RC Quad-
rocopter and the remote control, please carry out a new
frequency bind.
• Switch the model ON at the ON/OFF switch.
4a
• The LEDs on the quadrocopter light up continuously.
• Switch on the controller at the power switch.
• Push the left-hand joystick, i.e. the throttle lever,
right to the top, then fully downwards into the
zero position.
• The LEDs on the quadrocopter now flash rhyth-
mically. The binding has now been success-
fully established. The LED on the controller now
lights continuously.
or of the controller .
2a 2b
