PCE Instruments WSAC 50 Bedienungsanleitung Seite 3

English
Contents
1 Safety notes
2 Specifications
2.1 Technical specifications
2.2 Delivery contents
2.3 Order code
2.4 Accessories
3 System description
3.1 Device description
3.2 Electrical wiring
Pin assignment of „Signal Input" plug
3.3
3.4 Pin assignment RS485 interface plug
4 Getting started
4.1 Assembly
4.2 Power supply
4.3 Connecting the sensors
5 Operation
5.1 Measurement
5.2 Settings
6 RS-485 interface (optional)
6.1 Communication protocol
6.2 Standard setting
6.3 Excerpt from register addresses
7 Warranty
8 Disposal
© PCE Instruments
11
12
12
12
13
13
14
14
15
15
15
16
16
16
17
17
17
18
19
19
19
19
20
20
