Set description
Flashlight, 18350 Li-Ion 900 mAh battery, magnetic USB charger, clip,
lanyard, spare O-ring, user manual.
The producer reserves the right to change the package at his own
discretion without modifying this manual. Specifications are sub-
ject to change without notice.
Initial Service
TO SET/REPLACE BATTERY
1. Unscrew the tailcap.
2. Place the battery with the positive contact (+) facing the head of
the flashlight.
3. Adjust the tailcap and tighten it as far as it can go.
The flashlight is ready for operation.
HOW TO CONNECT THE MAGNETIC CHARGER
Unscrew the tailcap to 1/4 of a circle and adjust the magnetic charger
to it.
CHARGER COLOR INDICATION
Charger not plugged in:
• Green — device is in waiting mode.
Charger plugged in:
• Red blinking — unscrew the tailcap to 1/4 for charging.
• Red — charging with rated charging current is going on.
• Green — charging is finished.
REV_00-0000
Operation
Before use: Tighten the tailcap as far as it can go.
GENERAL TYPE
Modes: Firefly1, Firefly2, Main modes, Turbo mode (last used in
Advanced, Turbo2 by default).
In OFF state
1 click: To turn on the last used mode.
Press and hold: To start cycling through Firefly modes. Release to
select. Keeping button pressed will start cycling through Main modes.
In ON state
1 click: To turn off the flashlight.
Press and hold: To start cycling through Main modes from any mode. In
Firefly1 cycling through Main modes starts after cycling through Firefly
modes. Release to select.
2 clicks: To turn on Turbo mode from any mode. The second double click
brings back last used mode.
ADVANCED TYPE
To switch between types of operation unscrew the tailcap to 1/4 while
the flashlight is off, press the button and tighten the tailcap while
keeping the button pressed.
Sections of modes:
[1] – Firefly modes, [2] – Main modes, [3] – Turbo modes,
[4] – Strobe modes
In OFF state:
1 click: To turn on the last used mode.
Press and hold: To turn on Firefly1 mode [Section 1]. Keeping button
pressed will start cycling through modes: Firefly1 - Firefly2 - Firefly3 -
Main1 - Main2 - Main3 - Turbo1.
In ON state:
1 click: To turn off the flashlight.
Press and hold: To start cycling through the modes of relevant Section.
The same in OFF & ON states:
2 clicks: To turn on Main mode [Section 2]. Another double click will
switch between chosen modes in [Section 1] and [Section 2].
3 clicks: To turn on Turbo mode [Section 3].
4 clicks: To turn on Strobe mode [Section 4].
Automemorizing. After switching off the last used mode is memorized
for quick access at next switching on.
PRIME C1 PRO USER MANUAL ENG 3
