Engine Timing Tool Set for Volvo 2.0L (B4204)
TOOLS
1 Holder for camshaft sprocket locking tool, to be used as OEM 9997497
2 Crankshaft locking tool, to be used as OEM 9997495
3 Spindle for crankshaft gear puller, to be used as OEM 9997493
4 Screw
5 Retaining plate for crankshaft locking tool, to be used as OEM 9997495
6 Crankshaft gear puller, to be used as OEM 9997493
7 Radial seal ring assembly tool, to be used as OEM 9997496
8 Camshaft adjustment tool, to be used as OEM 9997490
9 Camshaft sprocket locking tool, to be used as OEM 9997497
10 Screw
ATTENTION
Read the operating instructions and all safety instructions contained therein carefully before using the
product. Use the product correctly, with care and only according to the intended purpose. Non-
compliance of the safety instructions may lead to damage, personal injury and to termination of the
warranty. Keep these instructions in a safe and dry location for future reference. Enclose the
operating instructions when handing over the product to third parties.

INTENDED USE

These tool set is used for adjusting and checking the engine timing on newer Volvo models with 2.0L
4 cylinder (B4204) engine and 8 speed transmission.
More information regarding this item and a list of suitable engines and models can be found on our
website: www.bgstechnic.com
