Precisa 321 Wartungsanleitung Seite 12

321
Pos. Pcs. Item number
1 1 N
2 1 N
3 1 see page 12
4 1 320-7006
5 2 320-2004
6 2 see page 12
7 1 N
8 8 see page 12
9 1 320-7130
1 360-5003
1 320-5023
10 1 360-7005
11 1 part of (10)
12 1 part of (10)
13 2 300-7024
14 1 320-3080
15 1 360-2001
16 1 N
17 1 320-2032
18 1 240-4048
19 1 N
20 1 N
21 3 PN 1100-060
22 2 PN 1100-023
23 2 PN 1100-040
24 11 PN 1100-169
25 3 PN 1100-170
26 8 PN 1100-171
27 6 PN 1100-172
28 2 PN 1100-173
29 3 PN 1100-286
30 3 PN 1300-008
31 2 PN 1500-062
32 25 PN 1500-075
33 2 PN 1500-097
34 6 320-3013
35 22 320-3055
36 3 320-3018
Item
Chassis
Balance arm
Coupling
Coil cpl.
Flexure holder
Vertical flexure
Support piece
Horizontal flexure
Inner cone round chromed, A
Inner cone square, M/C/D
Inner cone square, M/C/D, IP65
Floating sensor cpl.
Connection board
Temperature sensor board
Connection wire
Draft cover, A only
Cover support
Magnet cover
Transport safety device
Symmetry screw
Reference weight bearing left
Reference weight bearing right
Screw cyl. Phillips M3x4
Screw cyl. Phillips M3x6
Screw cyl. slot M3x8
Screw cyl. Torx M4x6
Screw cyl. Torx M4x8
Screw cyl. Torx M4x10
Screw cyl. Torx M4x12
Screw cyl. Torx M4x16
Grub screw M4x5
Nut hex-flanged M4
Washer M3
Spring washer M4
Washer brass M4
Base round
Base XR
Distance bolt
Components – Bestandteile
Artikel
Chassis
Waagbalken
Zugband
Spule kpl.
Lenker
Hängelager
Träger
Biegelager
Innenkonus rund verchromt, A
Innenkonus 4-kant, M/C/D
Innenkonus 4-kant, M/C/D, IP65
Lichtschranke kpl.
Verbindungsprint
Temperaturfühlerprint
Bronceband
Luftzugsdeckel, nur A
Deckelträger, nur A
Magnetdeckel
Transportsicherung
Symmetrieschraube
Referenzgewichtslager links
Referenzgewichtslager rechts
ZK-Schraube M3x4
ZK-Schraube M3x6
ZS-Schraube M3x8
ZT-Schraube M4x6
ZT-Schraube M4x8
ZT-Schraube M4x10
ZT-Schraube M4x12
ZT-Schraube M4x16
Gewindestift M4x5
6-KT-Mutter M4
Unterlagsscheibe M3
Spannscheibe M4
Unterlagsscheibe Messing M4
Beilage rund
Beilage XR
Distanzbolzen
11
