Danfoss HIDA9028A Bedienungsanleitung Seite 2

AME 55 QM
MAINTENANCE
FREE
❶
❷
④
❸
① 2×
AC 24 V
Connect via safety isolating
transformer.
②
2 | © Danfoss | 2021.09
5-95 % RH
no condensing
max 3 Nm
×
1
3-5 Nm
2 ×
Proportional 3 point/RL
=
AUTO
=
4 – 6 mm × 1 mm
120
55
①
2x
SN 0 V
SP 24 VAC
0(2)-10 V
Y
0(4)-20 mA
1
0 V
3
X 0(2)-10 V
AQ21258646994402-010201
13 mm 4 mm
②
③
2x
max 40 mm
Neutral
Power supply
Input
Input
Output
