Touchscreen for the MilTouch™ controller — This is a touch-sensitive display screen that
you use for most machine functions.
Door unlock button (
opened. This button is only active when the machine is idle and the water in the machine is below
door level.
This button is also part of the two-hand controls circuitry. When the machine is idle, this button
must be held depressed to perform the tilt functions. This requirement helps ensure that you have
both hands safely on the control panel of the machine and away from moving components.
Loading Controls
load and unload the machine.
Tilt direction switch (
cate the direction of movement of the machine. To tilt the machine, hold this switch in the desired
position while you hold the door unlock button (
Tilt the machine forward to the discharge position.
Tilt the machine to the neutral (non-tilted) position.
Jog direction switch (
clockwise or counterclockwise to help you load or unload the machine. The arrows indicate the
direction of rotation.
To rotate the cylinder, hold the jog direction switch in the desired position while you hold the
door unlock button (
Rotate the cylinder clockwise.
Rotate the cylinder counterclockwise.
NOTE: The jog feature is disabled on machines that are equipped with load cells.
BNVLUO01 / 2018513
2.2 Emergency Stop Switch (locking push button)
One or more emergency stop switches (pictured below) may be provided on the device. When
pressed, any emergency stop switch removes power from the machine controls, stops the ma-
chine, and locks in the depressed (switch actuated, machine stopped) position. When safe to do
so, turn the button clockwise to unlock the switch. To resume operation, perform the device's nor-
mal startup procedure.
