BOS R254K-UUI-LH12-S4
Photoelectric sensors
5
Primary device functions
5.1
Identification
5.1.1
Description
The identification data is used for the identification and
management of the IO-Link devices.
5.1.2
ISDU
Name
Index
Vendor Name
0x0010 (16)
Vendor text
0x0011 (17)
Product Name
0x0012 (18)
Product ID
0x0013 (19)
Product text
0x0014 (20)
Serial Number
0x0015 (21)
Hardware Revision
0x0016 (22)
Firmware Revision
0x0017 (23)
Application Specific
0x0018 (24)
Tag
Function Tag
0x0019 (25)
Location Tag
0x001A (26)
Product Type Code
0x0700 (1792)
Product Order Code
0x0701 (1793)
Tab. 5-1:
Identification – ISDU
Application Specific Tag
With the Application Specific Tag parameter, a string
(maximum 32 bytes) can be written to the device. This
value typically describes the application in which the
product is used.
Function Tag
With the Function Tag parameter, a string (maximum
32 bytes) can be written to the device. This value typically
describes the function of the product in the application
area.
Location Tag
With the Location Tag parameter, a string (maximum
32 bytes) can be written to the device. This value typically
describes the location of the product in the application
area.
www.balluff.com
Sub-
Access
Length
index
0
R
7 bytes
0
R
15 bytes
0
R
[...]
0
R
[...]
0
R
[...]
0
R
16 bytes
0
R
2 bytes
0
R
≤ 10 bytes
0
R/W
≤ 32 bytes
0
R/W
≤ 32 bytes
0
R/W
≤ 32 bytes
0
R
≤ 64 bytes
0
R
7 bytes
Product Type Code
The Balluff type code is stored permanently in the device.
Product Order Code
The Balluff order code is stored permanently in the device.
5.1.3
For an overview of all System Commands, see section 3.5
on page 25.
5.1.4
The functionality is available in all variants.
Data Type
Data
Storage
STRING
No
STRING
No
STRING
No
STRING
No
STRING
No
"Background suppression
STRING
No
STRING
No
STRING
No
STRING
Yes
STRING
Yes
STRING
Yes
STRING
No
STRING
No
System commands
Variant dependence
english
Default
"Balluff"
"www.balluff.com"
"BOS R254K-UUI-
LH12-S4 (ADSS)"
"BOS R254K-UUI-
LH12-S4 (ADSS)"
laser"
„***"
„***"
„***"
"BOS R254K-UUI-
LH12-S4 (ADSS)"
"BOS02C1"
29
