BOS R254K-UUI-LH12-S4
Photoelectric sensors
7
System functions (continued)
Logic
With Logic, the input/output can be configured as inverted
or normal.
Value Name Description
0x00 (0) Normal Non-inverted logic
0x01 (1) Inverted Inverted logic
Tab. 7-16: Pin Assignment – Logic
Type
The output can be configured with Type.
Value Name Description
Pin 2
0x00 (0) PNP PNP output
0x01 (1) NPN NPN output
Pin 2 and Pin 4
0x02 (2) Push-Pull Push-Pull output
Tab. 7-17: Pin Assignment – Type
7.5.3 System commands
For an overview of all System Commands, see section 3.5
on page 25.
