Set description
Flashlight, 18350 Li-Ion 900 mAh battery, Micro USB cable,
headmount, clip, spare O-ring, user manual.
The producer reserves the right to change the package at his own
discretion without modifying this manual. Specifications are sub-
ject to change without notice.
Initial Service
TO SET/REPLACE BATTERY
1. Unscrew the tailcap.
2. Place the battery with the positive contact (+) facing the head of
the flashlight.
3. Adjust the tailcap and tighten it as far as it can go.
The flashlight is ready for operation.
FLASHLIGHT CHARGING
Turn off the flashlight and connect the cable. Color indication in the
button displays the charging stage: red — the flashlight is charging,
green — the flashlight is charged. If there is no indication, the battery
is removed or installed in the wrong polarity. Approximate time for
charging a fully discharged battery is 2 h 30 min. We recommend using
adapters with 1A current and higher.
REV_00-0004
Operation
Before use: Tighten the tailcap as far as it can go.
In OFF state
1 click: To turn on the last used mode.
Press and hold: To start cycling through Firefly modes. Release to
select. Keeping button pressed will start cycling through Main modes.
In ON state
1 click: To turn off the flashlight.
Press and hold: To start cycling through Main modes from any mode. In
Firefly1 cycling through Main modes starts after cycling through Firefly
modes. Release to select.
2 clicks: To turn on Turbo mode from any mode. The second double click
brings back last used mode.
MOMENTARY ACCESS
Firefly. Press and hold the button in OFF state to start cycling through
Firefly modes. Release to select. Keeping button pressed will start
cycling through Main modes.
Main. Short click from OFF state activates Main mode if it was the last
used mode.
Turbo. Double click in any mode in ON state. The second double click
brings back last used mode.
Cycling through Main modes. In ON state press and hold the button
in any mode. Main modes will start switching cyclically. In Firefly1
cycling through Main modes starts after cycling through Firefly modes.
Release to select.
Lamp mode. The flashlight can work without battery in Firefly1,
Firefly2 and Main1 modes. For this connect the Micro USB cable to the
flashlight and power source, remove the battery.
1 click: To turn on/off the flashlight.
Press and hold: To start cycling through modes.
For activation of the timer, unscrew the tailcap to 1/4 while the
flashlight is off, press the button and tighten the tailcap while keeping
the button pressed.
Press and hold the button for 5 seconds. When the flashlight starts
flashing with the main LED, release the button. Press the button the
required number of times to set the timer:
1 click – 2 min; 2 clicks – 5 min; 3 clicks and more – 10 min.
The main LED will flash from 1 to 3 times, confirming the action:
1 flash – 2 min; 2 flashes – 5 min; 3 flashes – 10 min.
