Door right-left change
List of tools to be provided by the user
EN
Power off the refrigerator, and remove all objects from the door trays.
1.
Fix the door with tape.
2.
Dismantle the upper hinge cover, screws and upper hinge, and remove the plastic
3.
screw hole caps from the other side.
4.
dismantle the door and the bottom hinge assembly and adjustable foot, then
assemble the bottom hinge assembly and adjustable foot on other side.
5.
Dismantle the stopper under the door then assemble the stopper on the other
side.put the door on bottom hinge and assemble the upper hinge, upper hinge
cover andplastic screw hole caps successively.
Cross screwdriver
Putty knife / Thin-blade screwdriver
Masking tape
5/16" socket spanner
optional
optional
06
The upper hinge cover
The upper hinge cover
Upper hinge
Upper hinge
Hole cap
Hole cap
