Floppy
l 1 floppy port
l Supports 1 FDD with 360KB, 720KB, 1.2MB, 1.44MB and 2.88MB
TPM (Optional)
l Supports TPM
Connectors
l Rear panel
- 1 PS/2 mouse port
- 1 PS/2 keyboard port
- 1 parallel port
- 1 serial port
- 1 VGA port
- 1 LAN jack
- 4 USB 2.0 ports
- 3/ 6 audio jacks (Optional)
l On-Board Pinheaders/ Connectors
- 1 CD-In connector
- 1 S/PDIF-Out pinheader
- 1 serial port connector
- 2 USB 2.0 pinheaders
- 1 front panel audio pinheader
- 1 chassis intrusion switch pinheader
- 1 TPM pinheader (Optional)
Slots
l 1 PCI Express x16 slot
l 2 PCI slots, support 3.3V/ 5V PCI bus Interface

Form Factor

l Micro-ATX (24.4cm X 19.0cm)
Mounting
l 6 mounting holes
Important:
To reach the 8-channel sound effect, the 7th and 8th channels must be outputted from front
panel (pinheader) if you purchase the mainboard with 3 audio jacks.
3
