LED Features
Back Panel
Connectors
I/O Controller

Hardware Monitor

Form Factor

BIOS Features
8
Specifications
All manuals and user guides at all-guidesbox.com
Continued from previous column
∙ 1x EZ LED Control switch
∙ 1x 4-pin RGB LED connector
∙ 3x 3-pin RAINBOW LED connectors
∙ 4x EZ Debug LED
∙ 1x DisplayPort port
∙ 1x HDMI port
∙ 1x Flash BIOS button
∙ 2x USB 2.0 Type-A ports
∙ 2x USB 3.2 Gen1 5Gbps Type-A ports
∙ 1x LAN I225V port
∙ 3x USB 3.2 Gen 2 10Gbps Type-A port
∙ 1x USB 3.2 Gen 2x2 20Gbps Type-C port
∙ 2x Wi-Fi Antenna connectors
∙ 5x Audio jacks
∙ 1x Optical S/PDIF Out connector
NUVOTON NCT6687-R Controller Chip
∙ CPU/ System/ Chipset temperature detection
∙ CPU/ System/ Pump fan speed detection
∙ CPU/ System/ Pump fan speed control
∙ ATX Form Factor
∙ 12 in. x 9.6 in. (30.5 cm x 24.4 cm)
∙ 1x 256 Mb flash
∙ UEFI AMI BIOS
∙ ACPI 6.4, SMBIOS 3.4
∙ Multi-language
